Corrosion Resistant Hang Flange Bearing Unit

UCFB205 Short Base Square Flange Mounted Ball Bearing is a complete Bearing Assembly combined with UC205 insert bearing and FB205 Heavy-Duty Flange Mount. Different from conventional Hang Flange Bearing Unit, this compact bearing unit is designed for limited installation space. It has a 25mm bore, constructed of GCr15 bearing steel and HT200 grey cast iron housing, fitted with double-layer NBR oil seal and dual set screw locking structure. It features ±2° self-aligning capability to offset installation deviation and minor shaft deflection, lowering friction and improving transmission efficiency. Pre-filled with long-service lithium grease, it operates reliably from -20℃ to 100℃. With P0 precision grade, the recommended continuous running speed is under 3600r/min. The rigid short-base cast iron housing delivers excellent vibration resistance and anti-loosening performance to prevent unexpected shutdowns. As an integrated Bearing Assembly with universal interchangeable dimensions, it ena…
